Interlocking Cladding

Metroll Interlocking Cladding is a concealed fix wall cladding system ideal for both commercial and residential application. Panels can be installed horizontally, vertically or diagonally and with an adjustable shadow gap, making Metroll Interlocking Cladding a striking and versatile material choice.

Material Availability
0.55mm BMT COLORBOND® steel
COLORBOND® Ultra
COLORBOND® Metallic
ZINCALUME® steel

Installation Requirements
Galvanised Top Hats 1.15 x 35mm spaced at max. 900mm centres and fixed at max 500mm centres in perpendicular to direction of weatherboard. Breathable, waterproof membrane required. Fix weatherboard panel with a clip, to Top Hat at max. 500mm centres and max. 100mm from end of panel.

  • Horizontal, vertical or diagonal installation
  • Precise Sizing - 0.5mm tolerances
  • Install on top hat battens or timber studs
  • Residential and commercial application
  • Installs on curved structures
  • Concealed fixing
  • product shot of interlocking cladding
  • Interlocking cladding in situ on a commercial building

  • PDF Datasheet
Line drawing and specs of interlocking cladding
Dimensions of interlocking cladding
This product is available to purchase in Victoria only.
